| 1. Straight PCB receptacle | Board-mounted receptacle with a vertical connection, where this configuration is offered for the required SBMA interface. | Compact RF modules and board-to-board blind-mate layouts. | Check PCB footprint, board thickness, mounting method, alignment tolerance, and the specified mating interface. | Operating frequency, impedance, VSWR or return loss, insertion loss, and allowable misalignment—use values from the exact datasheet. |
| 2. Right-angle PCB receptacle | Board-mounted receptacle with a lateral connection, if available in the selected SBMA series. | Assemblies with limited vertical clearance or a side-entry RF path. | Verify orientation, board-edge clearance, solder or attachment requirements, and mechanical support under mating loads. | Overall height and footprint, RF performance across the intended band, and environmental ratings stated for the part. |
| 3. Flexible-cable termination | Cable-end connector assembly compatible with the specified SBMA mating interface, where offered. | Connections between equipment and RF modules where some cable routing flexibility is needed. | Match the connector to the exact cable type, outside diameter, center conductor, and termination method; confirm cable bend limits. | Cable loss, assembly frequency range, impedance, retention method, and any specified mating-cycle limit. |
| 4. Right-angle cable assembly | Cable assembly with an angled connector body, subject to availability in the required interface and cable family. | Dense enclosures where a straight cable exit would obstruct neighboring hardware. | Check exit direction, bend radius, connector envelope, cable strain relief, and clearance after installation. | Assembly-level RF data and mechanical dimensions; do not assume performance is identical to a straight version. |
| 5. Panel or bulkhead receptacle | Chassis-mounted receptacle with panel retention features, if the chosen SBMA series provides them. | Equipment panels and enclosures requiring a fixed RF connection point. | Confirm panel thickness, cutout dimensions, mounting hardware, grounding arrangement, and sealing requirements. | Panel-side dimensions, mounting torque guidance, corrosion-resistant finish details, and any stated ingress rating. |
| 6. Flange-mounted receptacle | Chassis or module receptacle secured by a flange; hole pattern and body style vary by product. | Secure mounting on RF modules, instrument panels, and assemblies exposed to repeated connection forces. | Compare flange footprint, hole spacing, fasteners, mounting surface, and alignment with the mating component. | Mechanical drawing, material and finish, RF performance, and environmental test conditions listed by the supplier. |
| 7. Interface adapter or test assembly | Adapter or short test assembly that connects the required SBMA interface to another specified interface; confirm exact end genders and geometry. | Bench testing, measurement setups, or temporary integration with existing RF equipment. | Check both interfaces, impedance, gender, frequency range, adapter length, and whether the setup requires calibration. | Insertion loss, return loss or VSWR, power limits, and traceable test data where required by the application. |
